Mask2Former

Mask2Former

For downloads and more information, please view on a desktop device.
Logo for Mask2Former
Description
Binary instance segmentation model trained on COCO data.
Publisher
NVIDIA
Latest Version
mask2former_swint_trainable_v1.0
Modified
November 12, 2024
Size
543.33 MB

TAO Pretrained Mask2former

Model Overview

Description

Masked-attention Mask Transformer or Mask2Former is a segmentation architecture capable of addressing panoptic, instance or semantic image segmentation tasks. The masked attention is essential in efficiently extracting localized features by constraining cross-attention within predicted mask regions.

This model is ready for non-commercial use.

Reference

  • B. Cheng, I. Misra, A.G. Schwing, A. Kirillov, R. Girdhar: Masked-attention Mask Transformer for Universal Image Segmentation

License

The licenses to use this model is covered by the Model EULA. By downloading the unpruned or pruned version of the model, you accept the terms and conditions of these licenses

Model Architecture

Architecture Type: The model in this instance is an instance segmentor that takes color (RGB) images as inputs and generates segmentation masks and associated labels as outputs. Network Architecture: The backbone feature extractor of this model is Swin-T model pretrained on ImageNet dataset.

Input

  • Input Type: Image
  • Input Formats: Red, Green, Blue (RGB)
  • Other Properties Related to Input:** Minimum 32 x 32 Resolution required; no alpha channel or bits

Output

  • Output Type: Label, Mask and Score for each detected object in the input image.
  • Output Format: Label and Score: One-Dimensional (1D), Mask: Two Dimensional (2D)
  • Other Properties Related to Output**
    • pred_classes: Batch size x Number of queries
    • pred_masks: Batch size x Number of queries x Height x Width
    • pred_scores: Batch size x Number of queries

How to Use This Model

This model needs to be used with NVIDIA Hardware and Software. For Hardware, the model can run on any NVIDIA GPU with sufficient memory (>12G). This model can only be used with TAO Toolkit.

The primary use case for these models is instance segmentation.

It is intended for training and fine-tune using Train Adapt Optimize (TAO) Toolkit and the users' dataset of object detection. High fidelity models can be trained to new use cases. A Jupyter notebook is available as a part of TAO container and can be used to re-train.

Instructions to Use Pretrained Models with TAO

To use these models as pretrained weights for transfer learning, use the following snippet as a template for the model and train components of the experiment spec file to train a Mask2former model. For more information on the experiment spec file, see the TAO Toolkit User Guide.

model:
  mode: "instance"
  backbone:
    type: "swin"
    swin:
      type: "tiny"
      window_size: 7
      ape: False
      pretrain_img_size: 224
  mask_former:
    num_object_queries: 100
  sem_seg_head:
    norm: "GN"
    num_classes: 1

Software Integration

Runtime Engine:

  • TAO 5.5.0

Supported Hardware Microarchitecture Compatibility:

  • NVIDIA Ampere
  • NVIDIA Blackwell
  • NVIDIA Hopper
  • NVIDIA Lovelace
  • NVIDIA Pascal
  • NVIDIA Turing
  • NVIDIA Volta

[Preferred/Supported] Operating System(s):

  • Linux

Model Versions

  • mask2former_swint_trainable_v1.0 - Pre-trained Mask2former model for finetuning or inference.
  • mask2former_swint_deployable_v1.0 - Pre-trained Mask2former model deployable to deepstream.

Training and Evaluation Datasets

Training Datasets

Link: https://cocodataset.org/

Data Collection Method by dataset: Unknown

Labeling Method by dataset: Human

Properties: The COCO dataset contains 118K training images and corresponding annotation files. The annotation includes bounding boxes and segmentation masks of the 80 thing categories. The categories were mapped to a single category or "object" to train the binary instance segmentation model.

Evaluation Datasets

Link: https://cocodataset.org/

Data Collection Method by dataset: Unknown

Labeling Method by dataset: Human

Properties: The COCO dataset contains 5K validation images and corresponding annotation files. The annotation includes bounding boxes and segmentation masks of the 80 thing categories. The categories were mapped to a single category or "object" to train the binary instance segmentation model.

Performance

Evaluation Data

We test the Mask2former model on the modified COCO 2017 validation dataset.

Methodology and KPI

The KPI for the evaluation data are reported below.

model Precision mIoU
Mask2former FP16 0.96

Inference

Engine: Tensor(RT)
Test Hardware:

  • A2
  • A30
  • DGX H100
  • DGX A100
  • DGX H100
  • JAO 64GB
  • Jetson AGX Xavier
  • L4
  • L40
  • NVIDIA T4
  • Orin
  • Orin Nano 8GB
  • Orin NX
  • Orin NX16GB
  • T4
  • Xavier NX

The inference is run on the provided unpruned model at FP16 precision. The inference performance is run using trtexec on Jetson AGX Xavier, Xavier NX, Orin, Orin NX and NVIDIA T4, and Ampere GPUs. The Jetson devices are running at Max-N configuration for maximum GPU frequency. The performance shown here is the inference only performance. The end-to-end performance with streaming video data might vary depending on other bottlenecks in the hardware and software.

Platform BS FPS
AGX Orin 64GB 8 17.53
Jetson Orin 16GB 8 7.19
Jetson Nano 8GB 8 2.13
T4 16 23.54
A30 16 73.94
A2 16 14.43
L4 16 35.27
L40 16 104.42
RTX4090 16 122.55
A100 16 147.11
H100 16 251.99
