NVTabular

For copy image paths and more information, please view on a desktop device.
Logo for NVTabular

Description

NVTabular is a feature engineering and preprocessing library for tabular data designed to quickly and easily manipulate terabyte scale datasets used to train deep learning based recommender systems. https://github.com/NVIDIA/NVTabular/

Publisher

NVIDIA

Latest Tag

0.3

Modified

December 4, 2020

Compressed Size

13.95 GB

Multinode Support

No

Multi-Arch Support

No

0.3 (Latest) Scan Results

No results available.

This container is deprecated, please use one of the NVTabular compatible containers found here.

NVTabular | API documentation

NVTabular is a feature engineering and preprocessing library for tabular data designed to quickly and easily manipulate terabyte scale datasets used to train deep learning based recommender systems. It provides a high level abstraction to simplify code and accelerates computation on the GPU using the RAPIDS Dask-cuDF library.

Recommender systems require massive datasets to train, particularly for deep learning based solutions. The transformation of these datasets after ETL in order to prepare them for model training is particularly challenging. Often the time taken to do steps such as feature engineering, categorical encoding and normalization of continuous variables exceeds the time it takes to train a model.

A part of the Merlin ecosystem, NVTabular works with other NVIDIA components including HugeCTR and Triton Inference Server to provide end to end acceleration of recommender systems on the GPU.

NVTabular is designed to support Data Scientists and ML Engineers trying to train (deep learning) recommender systems or other tabular data problems by allowing them to:

  • Prepare datasets quickly and easily in order to experiment more and train more models.
  • Work with datasets that exceed GPU and CPU memory without having to worry about scale.
  • Focus on what to do with the data, and not how to do it, using our abstraction at the operation level.

It is also meant to help ML/Ops Engineers deploying models into production by providing:

  • Faster dataset transformation, allowing for production models to be trained more frequently and kept up to date, helping improve responsiveness and model performance.
  • Integration with model serving frameworks like NVIDIA’s Triton Inference Server and Tensorflow Serving to make model deployment easy. (WIP)
  • Statistical monitoring of the dataset for distributional shift and outlier detection during production training or inference. (WIP)

The library is designed to be interoperable with both PyTorch and TensorFlow using dataloaders that we have developed as extensions of native framework code. NVTabular provides the option to shuffle data during preprocessing, allowing the dataloader to load large contiguous chunks from files rather than individual elements. This allows us to do per epoch shuffles orders of magnitude faster than a full shuffle of the dataset. Loading tabular data is almost always a training bottleneck and in our benchmarking we have seen 10x improvements in training time on GPU relative to the native dataloaders.

Extending beyond model training, we plan to provide integration with model serving frameworks like NVIDIA’s Triton Inference Server, creating a clear path to production inference for these models and allowing the feature engineering and preprocessing steps performed on the data during training to be automatically applied to incoming data during inference.

Our goal is faster iteration on massive tabular datasets, both for experimentation during training, and also for production model responsiveness.

Getting Started

NVTabular is available in the NVIDIA container repository at the following location: http://ngc.nvidia.com/catalog/containers/nvidia:nvtabular.

Currently we have the beta release (0.2) container, you can pull the container using the following command:

docker run --runtime=nvidia --rm -it -p 8888:8888 -p 8797:8787 -p 8796:8786 --ipc=host --cap-add SYS_PTRACE nvcr.io/nvidia/nvtabular:0.2 /bin/bash

If you are running on a docker version 19+, change --runtime=nvidia to --gpus all.

The container will open a shell when the run command completes execution, you will be responsible for starting the jupyter lab on the docker container. Should look similar to below:

(rapids)root@2efa5b50b909:

Finally start the jupyter-lab server:

jupyter-lab --allow-root --ip='0.0.0.0' --NotebookApp.token=''

Now you can use any browser to access the jupyter-lab server, via :8888

Once in the server, navigate to the /nvtabular/ directory and explore the code base or try out some of the examples.

Within the container is the codebase, along with all of our dependencies, particularly RAPIDS Dask-cuDF, and a range of examples. The easiest way to get started is to simply launch the container above and explore the examples within.

The code base with examples, can be found at the following directory location within the container:

/nvtabular/

Conda

NVTabular can be installed with Anaconda from the nvidia channel:

conda install -c nvidia -c rapidsai -c numba -c conda-forge nvtabular python=3.6 cudatoolkit=10.2

Examples and Tutorials

Examples of the usage of NVTabular for preprocessing and feature engineering and for dataloading in Tensorflow, PyTorch and HugeCTR can be found in our API documentation examples section.

Performance of the Criteo DRLM workflow demonstrates the effectiveness of the NVTabular library. The original ETL script provided in Numpy took over five days to complete. Combined with CPU training the total iteration time is over one week. By optimizing the ETL code in spark and running on a DGX-1 equivalent cluster we were able to bring that time down to three hours for ETL and one hour for training.

With NVTabular on a single V100 32GB GPU we are able to complete ETL in 13 minutes, and using a DGX-1 cluster of eight V100 GPUs we can accelerate ETL to 3 minutes. Combined with HugeCTR we can process the dataset and train the full model in only 6 minutes. This fast iteration is the goal of NVTabular and the Merlin application framework. We're working on A100 benchmarks and will share as soon as they are available.

We also have a simple tutorial that demonstrates similar functionality on a much smaller dataset, providing a pipeline for the Rossman store sales dataset fed into a fast.ai tabular data model.

Contributing

If you wish to contribute to the library directly please see Contributing.md. We are particulary interested in contributions or feature requests for feature engineering or preprocessing operations that you have found helpful in your own workflows.

Learn More

If you are interested in learning more about how NVTabular works under the hood we have provided this more detailed description of the core functionality.

We also have API documentation that outlines in detail the specifics of the calls available within the library.
