What Is DIGITS?
The NVIDIA Deep Learning GPU Training System (DIGITS) puts the power of deep learning into the hands of engineers and data scientists.
DIGITS can be used to rapidly train the highly accurate deep neural network (DNNs) for image classification, segmentation and object detection tasks.
DIGITS simplifies common deep learning tasks such as managing data, designing and training neural networks on multi-GPU systems, monitoring performance in real time with advanced visualizations, and selecting the best performing model from the results browser for deployment.
DIGITS is completely interactive so that data scientists can focus on designing and training networks rather than programming and debugging.
Before you can run an NGC deep learning framework container, your Docker environment must support NVIDIA GPUs. To run a container, issue the appropriate command as explained in the Running A Container chapter in the NVIDIA Containers And Frameworks User Guide and specify the registry, repository, and tags. For more information about using NGC, refer to the NGC Container User Guide.
The method implemented in your system depends on the DGX OS version installed (for DGX systems), the specific NGC Cloud Image provided by a Cloud Service Provider, or the software that you have installed in preparation for running NGC containers on TITAN PCs, Quadro PCs, or vGPUs.
Select the Tags tab and locate the container image release that you want to run.
In the Pull Tag column, click the icon to copy the
Open a command prompt and paste the pull command. The pulling of the container image begins. Ensure the pull completes successfully before proceeding to the next step.
Run the container image.
If you have Docker 19.03 or later, a typical command to launch the container is:
docker run --gpus all -it --rm -v local_dir:container_dir nvcr.io/nvidia/digits:xx.xx-framework
If you have Docker 19.02 or earlier, a typical command to launch the container is:
nvidia-docker run -it --rm -v local_dir:container_dir nvcr.io/nvidia/digits:xx.xx-framework
-itmeans run in interactive mode
--rmwill delete the container when finished
-vis the mounting directory
local_diris the directory or file from your host system (absolute path) that you want to access from inside your container. For example, the
local_dirin the following path is
If you are inside the container, for example,
ls /data/mnist, you will see the same files as if you issued the
ls /home/jsmith/data/mnist command from outside the container.
container_diris the target directory when you are inside your container. For example,
/data/mnistis the target directory in the example:
xx.xxis the container version. For example,
frameworkis the framework name. For example,
a. To run the server as a daemon and expose port 5000 in the container to port 8888 on your host:
docker run --gpus all --name digits -d -p 8888:5000
b. To mount one local directory containing your data (read-only), and another for writing your DIGITS jobs:
docker run --gpus all --name digits -d -p 8888:5000 -v
/home/username/data:/data:ro -v /home/username/digits- jobs:/workspace/jobs nvcr.io/nvidia/digits:xx.xx-framework ``` Note: In order to share data between ranks, NCCL may require shared system memory for IPC and pinned (page-locked) system memory resources. The operating systemâs limits on these resources may need to be increased accordingly. Refer to your systemâs documentation for details. In particular, Docker containers default to limited shared and pinned memory resources. When using NCCL inside a container, it is recommended that you increase these resources by issuing:
--shm-size=1g --ulimit memlock=-1
in the command line to:
docker run --gpus all
/workspace/README.mdinside the container for information on customizing your DIGITS image.
For the latest Release Notes, see the DIGITS Release Notes Documentation website.
For a full list of the supported software and specific versions that come packaged with this framework based on the container image, see the Frameworks Support Matrix.
For more information about DIGITS, see:
Note: There may be slight variations between the NVIDIA-docker images and this image.
To review known CVEs on the 21.07 image, please refer to the Known Issues section of the Product Release Notes.
